WT-40 Fence Pipe

Wheatland Tube Company will certify that all Wheatland WT-40 pipe is
manufactured in the USA and is in compliance with applicable local, state
and federal specifications. "WT-40 MADE IN USA" is proudly displayed on
each length of WT-40 pipe.


Specifying Agencies
Wheatland WT-40 meets or exceeds the following specifications.
• American Associations of State Highway and Transportation Officials
AASHTO M181
• Federal Specifications RR-F-191/2E and RR-F-191/3E
• Army Corps of Engineers UFGS-32 31 13
• Department of the Navy
• Federal Highway Administration
• Federal Aviation Administration AC150/5370-10C ITEM F-162
• U.S. Department of Justice - Federal Bureau of Prisons
• ASTM Specification F1043 Group IC Standard Specification for Strength and
Protective Coatings
• American Institute of Architects (AIA) MASTERSPEC


High Strength Spec Fence Framework
The strength and corrosion characteristics of Wheatland WT-40 fence pipe
have been tested, documented and certified by independent testing agencies
to ensure complete compliance with ASTM F1043 Group IC andAASHTO
M181. WheatlandWT-40 fence framework meets or exceeds the most
demanding specifications and codes imposed by private, independent and
government agencies.


WT-40 Technical Specifications
Scope

This specification covers WT-40 galvanized steel fence pipe as per ASTM
F1043 Group IC as manufactured by Wheatland Tube Company.





WT-40 Fence Specifications

Wheatland WT-40 fence framework



wheatland pipe build



FOUR LAYERS OF PROTECTION ENHANCED WITH COLOR
Galvanized coating + intermediate conversion coating
+clear polymer coating + polyester WT-ColorCoat



wheatland color

wheatland color



WT-ColorCoat is available with:
WT-40
WT-30
WT-20
WT-15
Tubing Wall 0.065 -- 0.055



WT-ColorCoat dark green and black colors are in compliance with ASTM F 934 "Standard Specifi cation for Standard Colors for Polymer- Coated Chain Link Fence Materials" Wheatland's 3 mil Polyester TGIC Powder WT-Color Coat meets or exceeds the coating requirements of ASTM F 1043 Standard Specification for Strength and Protective Coatings on Steel Industrial Chain Link Fence Framework"
